The Honestflex food suction and delivery hose is a specialized delivery system designed for the food, beverage, and dairy industries. While meeting the demands for efficient material transport, it prioritizes food safety. The hose features a multi-layered precision structure: the inner layer is made of smooth, white, food-grade rubber with a non-toxic and odorless formula, ensuring that the transported medium does not chemically react with the hose wall, thus preserving the pure flavor and original quality of the food; the reinforcing layer uses high-tensile-strength industrial filaments with a steel wire spiral support, giving the hose excellent resistance to negative pressure and pressure resistance, suitable for both suction and pressure delivery; the outer layer is made of highly wear-resistant and weather-resistant synthetic rubber, which can be made into smooth or corrugated surfaces as needed, and is available in a variety of colors for easy on-site identification and management. This product is manufactured in strict accordance with FDA food contact material standards. All raw materials undergo rigorous screening to ensure compliance with the stringent requirements of the food industry for hygiene and safety, resistance to detergent corrosion, and tolerance to frequent cleaning and disinfection processes. The hose's extremely smooth inner wall results in low fluid resistance and easy cleaning, effectively preventing bacterial growth, making it an ideal choice for the food processing, dairy beverage, and brewing industries.
Dairy Product Conveying: Suitable for raw milk collection at dairy farms, milk and cream conveying within dairy plants, yogurt filling lines, and the transfer of various liquid dairy products, ensuring product safety and hygiene.
Beverage Filling and Conveying: Widely used in the production and conveying of non-alcoholic beverages such as fruit juice, concentrates, soft drinks, purified water, and mineral water, meeting high-frequency cleaning requirements.
Edible Oil and Fermentation Conveying: Suitable for the suction and pressure conveying of vegetable oils, animal fats, and various liquid oils used in the food industry, exhibiting excellent oil resistance.
Brewing and Fermentation Industry: Used for conveying the raw materials for fermented beverages such as beer, wine, and rice wine, as well as material transfer between fermentation tanks, without affecting the flavor of the beverage.
Food Processing Raw Material Conveying: Suitable for the pipeline conveying of semi-finished raw materials such as liquid syrups, chocolate syrups, egg liquid, seasoning sauces, and whey on production lines.
Pharmaceuticals and Fine Chemicals: Under the condition of meeting food-grade requirements, it can also be used for conveying liquid raw materials with high hygiene requirements in some pharmaceutical and daily chemical industries.
Food-Grade Safety Guarantee: The inner layer is made of FDA-compliant food-grade, non-toxic, and odorless rubber. It will not chemically react with the conveying medium, will not release harmful substances, and ensures food safety and original flavor.
Excellent Chemical Resistance: It can withstand corrosion from common food processing agents such as citric acid and lactic acid, as well as various disinfectants and cleaning solutions, meeting the frequent cleaning requirements of CIP online cleaning systems.
Dual-Function Conveying Capacity: The reinforcing layer uses a composite structure of high-strength industrial filaments and steel wire spirals. It can maintain tube stability and prevent flattening under negative pressure conditions, and withstand stable pressure under positive pressure conveying conditions, making it a multi-purpose tube.
Easy-to-Clean Smooth Inner Wall: The extremely smooth inner wall results in low fluid resistance, high material conveying efficiency, and minimal material residue and bacterial growth. Cleaning is quick and thorough, meeting the stringent hygiene management requirements of the food industry.
High-strength, wear-resistant outer layer: The outer layer is made of highly wear-resistant synthetic rubber, capable of withstanding wear caused by dragging on processing workshop floors, friction against equipment frames, and frequent movement, extending the service life of the hose under harsh operating conditions.
Wide temperature range adaptability: Operating temperature range covers -32°C to +80°C, adapting to the low-temperature environment of frozen food workshops while also meeting the needs of general hot water cleaning and pasteurization processes.
Clear labeling and customization services: The outer layer is available in multiple colors as needed, facilitating pipe management by material type. OEM brand customization services are also available, supporting mandrel manufacturing to ensure dimensional accuracy.
I.D. | O.D. | W.P. | B.P. | Length | ||||
inch | mm | mm | bar | psi | bar | psi | m | ft |
3/4" | 19.1 | 31 | 10 | 150 | 30 | 450 | 61 | 200 |
1" | 25.4 | 37 | 10 | 150 | 30 | 450 | 61 | 200 |
1-1/4" | 31.8 | 44 | 10 | 150 | 30 | 450 | 61 | 200 |
1-1/2" | 38.1 | 51 | 10 | 150 | 30 | 450 | 61 | 200 |
2" | 50.8 | 64 | 10 | 150 | 30 | 450 | 61 | 200 |
2-1/2" | 63.5 | 80 | 10 | 150 | 30 | 450 | 61 | 200 |
3" | 76.2 | 92 | 10 | 150 | 30 | 450 | 61 | 200 |
3-1/2" | 89 | 105 | 10 | 150 | 30 | 450 | 61 | 200 |
4" | 101.6 | 120 | 10 | 150 | 30 | 450 | 61 | 200 |
6" | 152 | 172 | 10 | 150 | 30 | 450 | 30.5 | 100 |
Q1: What types of food products can this Food Suction And Delivery Hose handle?
This hose is specifically designed for the transfer of a wide variety of edible liquids, including milk and dairy products, fruit juices, wine, beer, edible vegetable oils, liquid sugar, syrups, drinking water, and other non-oily food substances requiring hygienic handling.
Q2: What is the working temperature range of the hose?
The Food Suction And Delivery Hose operates effectively within a temperature range of approximately -32°C to +80°C for standard applications. For specific high-temperature cleaning or hot-fill applications, please consult our engineering team for appropriate material selections.
Q3: Is this hose compliant with food safety regulations?
Yes. The hose is manufactured using non-toxic, odorless, and tasteless materials that comply with major international food contact standards, including FDA (U.S. Food and Drug Administration) requirements, EU 10/2011 regulations, and relevant local food safety certifications for materials intended for repeated contact with food products.
Q4: What are the available sizes and pressure ratings?
The hose is available in a wide range of inner diameters, typically from 19.1 mm to 152 mm. Working pressure and full vacuum ratings vary by size, construction, and operating temperature. Custom sizes and pressure specifications can be manufactured upon request to meet specific processing requirements.
Q5: Can the hose be supplied with sanitary end fittings?
Yes, the hose can be customized with a variety of hygienic connection types to suit food processing equipment, including stainless steel sanitary tri-clamp fittings, flanges, IDF and SMS fittings, as well as camlock couplings and threaded connections suitable for food-grade applications.
Q6: What standards or certifications does this hose meet?
This hose is manufactured in accordance with international food-grade standards. Certifications may include FDA compliance for materials in contact with food, EU food contact material regulations, and depending on specific requirements, can be supplied with supporting documentation for audit and inspection purposes.
Q7: What is the standard hose length?
Standard hose lengths are typically 10 meters, 20 meters, or 30 meters in continuous lengths. Custom lengths can be produced in coils or cut pieces to meet specific installation requirements and minimize waste in processing facilities.
Q8: Is this hose suitable for Clean-in-Place (CIP) procedures?
Yes, the hose is designed to withstand regular cleaning and sanitization cycles. It resists degradation from common CIP chemicals, including mild acids, alkalis, and sanitizing agents, as well as hot water washing, ensuring long service life in hygienic processing environments.
Q9: Can this hose be used for suction applications in food processing?
Absolutely. The embedded steel wire helix provides full vacuum resistance, preventing collapse during suction operations. This makes it ideal for emptying tanks, transferring from storage vessels, or pumping from tankers where negative pressure is present.
Q10: What type of reinforcement is used in this hose, and is it suitable for food contact?
The hose features high-strength textile cord reinforcement combined with an embedded steel wire helix, providing excellent vacuum resistance, pressure stability, and kink resistance. All materials in contact with the conveyed product, including the inner tube, are food-grade and non-toxic. The reinforcement layers are encapsulated within the hose wall and do not contact the product stream.
