Industrial Hose and Hydraulic Hose Applications by Industry

DIN EN853 1SN / SAE 100 R1 AT Structure:
Inner Tube: oil-resistant synthetic rubber.
Reinforcement: 1 braid of high-tensile steel wire.
Cover: weather- and oil-resistant synthetic rubber.

DIN EN853 2SN / SAE 100R2AT  Structure:
it is composed of three parts: tube, reinforcement and cover.
Inner Tube: black oil resistant synthetic rubber.
Reinforcement: two braids of high-tensile steel wire.
Cover: black oil, corrosion and abrasion resistant synthetic rubber.

Inner Tube: oil-resistant synthetic rubber.
Reinforcement: two high tensile polyester fiber braided.
Cover: weather- and oil-resistant synthetic rubber.
Temperature Range: -40℃ to +100℃.
Main Applications: Low-medium pressure lines, return lines
Applicable Standards: ISO 4079 R3, EN 854 R3, SAE J517 100R3

Inner Tube: Oil resistant synthetic nitrile rubber
Reinforcement: 2 layer or 4 layers of high strength synthetic textile and helix steel wire
Cover: Oil and weather resistant synthetic rubber
Application: petroleum base and water base hydraulic fluids
Temperature Range: -40℃(-104F)to+100℃(+212F)

One Layer Wire Braid, Textile Cover Hydraulic Hose
Inner Tube: Oil resistantsynthetic nitrilerubber
Reinforcement: Single layer of steel wire braided
Cover: Single layer of fibre braided
Application: Petroleum base and waterbase hydraulic fluids

SAE 100R6 One Layer Fiber Braid Hydraulic Hose
Inner Tube: oil resistant syntheticnitrile rubber
Reinforcement: Single layer of fibre braided
Cover: Oil and weather resistant synthetic rubber
Application: petroleum base and water base hydraulic fluids
Temperature Range: -40℃ (-104F)to+100℃(+212F)
Surface: Wrapped surface,Smooth surface

Inner Tube:Oil resistant seamless thermoplastic Polyamide(PA)tube.
Reinforcement: one or two layer braided high tensile synthetic fibre.
Cover:Blackhigh abrasion resistant polyurethane.
Application: Medium pressure hydraulic and pneumatic systems. Meets or exceeds SAE 100R7 requirements.For pneumatic or gaseous systems,use perforated(pin-pricked)hose
Temperature Range: -40℃(-104F)to+100℃(+212F)

Inner Tube: Oilresistant seamless thermoplastic Polyamide(PA)tube.
Reinforcement : one or two layer braided hightensile aramid fibre
Cover: Black high abrasion resistant polyurethane.
Application : Medium pressure hydraulic and pneumatic systems. Meets orexceeds SAE 100R8 requirements. For pneumaticor gaseous systems,use perforated(pin-pricked)hose.
Temperature Range :-40℃(-104 F)to+100℃(+212F)

Tube: Synthetic rubber,resistant against hydraulic fluids
Reinforcement: Two braids of high tensile steel wire
Cover : Abrasion and ozone resistant synthetic rubber
Temperature range: -40℃ to 100℃/-40°F to+212°F(max 120℃/248°F intermittent)

Compact, One Layer Steel Wire Reinforced Hydraulic Hose
Inner Tube:Oil resistant synthetic nitrile rubber
Reinforcement : One layer of high-tensile steel wire braided
Cover: Oil and weather resistant syntheticrubber
Application : Petroleumbase and water base hydraulic fluids
Surface :Wrapped surface,smooth surface
Temperature Range:-40℃(-104F)to+100℃(+212F)

Compressed air 40 bar(600psi)---Steel braided

Tube: NR & SBR synthetic rubber, black color.
Reinforcement: 1ply or 2ply high tensile polyester thread braiding
Cover: NR & SBR synthetic rubber, smooth or wrapped surface, black, yellow, red available

Tube: White, smooth, NR, NBR or EPDM food quality rubber
Reinforcement: Multi plies high strength synthetic fabric and helix wire
Cover: smooth(wrapped finish), synthetic rubber, blue or white, weathering resistant.
Application: FDA approved food hose designed for the delivery of foods such as milk, Juice, beer, edible oil, daily products etc.
Working Temperature: -32℃ to 80℃(-90℉ to +176℉)

Fuel Hose Construction:
Tube: Black, smooth, NBR rubber.
Reinforcement: High strength synthetic yarn.
Cover: Ozone, oil resistant synthetic nitrile rubber.
Working Temperature: -32°C to +82°C (-90°F to +180°F)
Application: Softwall hose Designed for the discharge of petroleum-based products, diesel, gasoline, lubricants, fuel, with aromatic content up to 50%.

Tube: White, Smooth Ultra High Molecular Weight Polyethylene (UHMWPE), EPDM
Reinforcement: Multi plies high strength synthetic fabric and helix wire.
Cover: EPDM resistant to chemical, weathering and ozone, blue, green wrapped or corrugated.
Application: Designed for in-plant or tank truck use, suction and discharge of chemicals and solvents.
Working Temperature: -40℃ to + 120℃((-72℉ to +248℉)

Jackhammer Air Hose Construction:
Tube: NR & SBR synthetic rubber, black color.
Reinforcement: 1ply or 2ply high tensile polyester thread braiding
Cover: NR & SBR synthetic rubber, smooth or wrapped surfac, black, yellow, red available

Tube: Black ,smooth, NR synthetic rubber
Reinforcement: Multi ply High strength synthetic fabric
Cover: Black, smooth(wrapped), abrasion resistant NR synthetic rubber
Application: Softwall abrasion resistant hose designed for the delivery of steel shots,sand, bead blasting application
Working Temperature: -40℃ to +70℃(-40℉ to +158℉)

Water Suction And Discharge Hose Construction:
Tube: Black, smooth, NR, SBR rubber compound.
Reinforcement: Multi plies High strength synthetic fibre and helix steel wire
Cover: Black, smooth, cloth impression, SBR rubber compound

Inner tube: Internal core in polyamide
Reinforcement: 1 or 2 high tensile aramidic braid or steel wire braid
Outer tube: pin pricked polurethane high abrasion resistance
Safety factor: 3:1
Features:Seamless nylon inner core compatible with most paints, coatings and solvents.Polyurethane cover provides superior abrasion resistance.
Special construction keeps hose lightweight and flexible.A special static drain element dissipates static charge.Date coding on the coupling provides traceability.Available in 3/16", 1/4" and 3/8" with working pressure to 3500 PSI.
Application:high pressure airless spray systems,chemical resistance solvents and aggressive fluids
Temperature range: -40℃ (-40 °F)   -  100℃ （+212 °F）max temperature recommended for water base hydraulic fluids and air : +70℃ (+ 158°F)

Application:Lightweight and flexible with abrasion resistant cover for agricultural chemicals and general industrial use. External helix provides for easy drag. Suitable for full vacuum.
Construction:Tube- Smooth, black (rubber) EPDM
Cover- Green polyethylene helix
Temperature Range:-40°C to +60°C (-40°F to +140°F)
Standard Lengths:100ft cut to multiples of 5ft at no charge

Tube and Cover: PVC, blue pvc layflat hose​, orange, red.
Reinforcement: high tensile polyester braiding
Application: PVC layflat hose is designed for light and heavy duty applications,the hoses are most commonly used in agricultural equipment where continuous water flow through irrigation systems is required. Other appliaction include water pump, pool & spa, construction, mines and marine.

Tube and cover: transparent PVC
Reinforcement: steel wire spiral
Working Temperature: -10℃(-50℉) to 65℃(+150℉)

● Lightweight, flexible with small bending radius.
● Durable against the external impact,chemical and climate
● Transparent, easy to check the contents.
● Anti-UV, anti-aginglong working life

Pvc Suction Hose Construction: High quality pvc with rigid pvc helix
Applications: drainage, and for transporting various powdery particles and liquids, it is widely used in civil and building works , agriculture, mining, construction, ship and fishery.
Working Temperature: -10℃(-50℉) to 65℃(+150℉)

● Economical & flexible
● Abrasion & chemical resistant
● Impact & crush resistant
● Excellent bending radius
● Constructed with rigid spiral helix reinforcement
● Smooth inner construction for unrestricted flow of materials

Tube: PVC material
Reinforcement: 1ply or 2ply high tensile polyester braiding
Cover: PVC, black, red, yellow, blue.
Working Temperature: -10℃(-50℉) to 65℃(+150℉)
Application: The PVC air hose is widely used in pneumatic tools, air compressors, Rock drill, automated air line, air supply, cleaning equipment, construction equipment and so on.
● High tensile polyester reinforced
● Work under high pressure 300psi
● Strong peeling adhesion between fibre and pvc
● light,flexible,non-kinking,non-twisting
● UV and ozone resistant,weather resistant
● Can be used for jackhammer hose

Tube and Cover: PVC
Application:PVC transparent hose is used for conveying water,oil,gas under normal working condition in factories,farm,ship,building and family.
Characteristic:
1.Flexible, light, transparent
2.Food grade, non-toxic, without odor
3.Anti-erosion and anti-abrasion
4.Anti-aging, long working life
Temperature: -10℃(-50℉) to 65℃(+150℉)

Tube: PVC
Reinforcement: 1 or 2 layers of high tensile strength polyester fibre.
Cover: PVC, Anti-UV, Anti-aging.
Working Temperature: -10℃(-50℉) to 65℃(+150℉)
Application: The hose is widely used in high pressure washer, air compressors and pneumatic tools. In agriculture, the high pressure pvc spray hose is used for spraying of pesticide, fungicide, fertilizer solution.

● Being made of tough PVC materials
● high tensile polyester braiding
● light weight, flexible, durable, anti-erosion
● Good flexibility and Non-kinking.

Tube and Cover: PVC
Reinforcement: high tensile polyester fibre.
Application: Being widely used for garden watering and car washing,household cleaning, in the parks, community, factories and families.
Working Temperature: -10℃(-50℉) to 65℃(+150℉)
● high pressure resistance, no leakage
● Anti-abrasion, Anti- UV, long working life
● Non toxic, Without odor
● Lightweight and flexible, easy to coil

Tube and Cover: PVC
Reinforcement: high tensile polyester fibre
Working Temperature: -10℃(-50℉)to 65℃(+150℉)
Application: PVC fibre reinforced hose is used for conveying water,oil,gas under normal working condition in the factory, farm, ship, building and family. The hose used for foodstuffs is made of special food grade material, It can also be used for conveying milk, beverage, distilled liquor, beer, jam and other foods, It can be used as pvc shower hose too.
● Flexible, transparent, durable, non-toxic, without odor
● Anti-erosion and anti-abrasion
● Adding colorful symbol lines on the surface of the hose

MaterialPP (Polypropylene)
Working Temperature: -50℃ (-122 ℉ ) to +80℃ (+176 ℉ )
Application: The use of spiral hose guard is an economical and convenient method of protecting and extending the life of hydraulic and pneumatic hoses, cables, wires and rope from premature wear. Spiral hose guard willwithstand the extremes of climate and operating conditions. Spiral Guard Wrap protects against abrasion, cuts, crushing, UV and various hazards Spiral Guard Wrap’s open spiral design allows for simple installation in the field, without the need to disconnect lines.
● Resistant to acids, oils and solvents
● Flexible
● UV resistance
● Excellent for use in temperature range from -50°C up to +80°C (continuous) / 100°C (short time)
● Protect hose increases usable life of hose Recyclable

Silicone Fire Sleeve Characteristic:
● This casing pipe is made with glass fiber and covered with thick iron oxide red silica gel.
● Fire resistant, flame retardant, heat insulation, insulation, anti-aging.
● Protect hoses and lines from molten metals, slag, welding splatter, electrical or grinding sparks and contamination.
Temperature: 260~300℃ (outside) 500~600℃ (inner)
