Application: Suitable for use and recommended for flowback water transfer, mining dewatering, long-distance fresh water transfer.
Inner tube and cover: Smooth TPE-P cover and tube.
Reinforcement: Circular woven polyester jacket
Operating Temperature Range: From -60° F to 176° F (-50° C to 80° C)
Standard Color: Blue, black, other colors available per request
Standard Length: 300ft/91.5m, 330ft/100m, 660ft/200m; other lengths available per request;
Couplings: Storz couplings, Camlocks etc.
Availability:
Quantity:

Honestflex is one type of through-the-weave TPE-P covered   hose   which   is   made   of  TPE-P   materials approved  according  to  NSF  61  standard.  Backflex hoses shall be made from  100% high tenacity virgin synthetic yarn circular woven and completely, totally embedded    in     the     TPE-P    compound,     excellent protected   against   mechanical   damage,   forming   a single  homogenous  construction  without  the  use  of any glues or adhesives of any type.

Honestflex performs excellently in age-resistance. It is theoretically supposed to be used for 30-50 years.Honestflex  is  a press-flat hose  and  can  keep  round shape  under  the  condition  of  no  pressure.  Honestflex hoses can be pressed flat and can be easily laid down and retrieved as layflat hoses.

ID

Wall Thickness

Weight

Working Pressure

Bursting Pressure

Inch

mm

Inch

mm

lbs/ft

kg/m

PSI/bar

PSI/bar

2”

52+1.5

0.10”

2.4

0.35

0.52

300PSI/21bar

900PSI/63bar

3”

77+2.0

0.10”

2.5

0.61

0.90

250PSI/17bar

750PSI/51bar

4”

104+2.0

0.13”

3.0

0.89

1.33

250PSI/17bar

750PSI/51bar

6”

155+2.5

0.15”

3.8

1.60

2.38

200PSI/14bar

600PSI/42bar

8”

204+3.0

0.17”

4.3

2.17

3.23

200PSI/14bar

600PSI/42bar
